Linglong is famous China Rigid Dump Truck Tires manufacturers and suppliers. Our factory specializes in manufacturing of Rigid Dump Truck Tires. Welcome to buy Rigid Dump Truck Tire from Linglong. Every requirement from customers will be replied within 24 hours.
These tires are used in quarries, mines and also on large construction sites. Conditions of usage can be significantly diverse, but the operating requirements remain the same: reliability, efficiency and profitability. Depending on your technical constraints, attaining these objectives requires very different solutions.
With a sturdy construction that can handle even the toughest jobs, these tires are sure to be a reliable choice for your heavy-duty vehicles. No matter what you're working in construction, mining, or any other industry that needs tough tires, our Rigid Dump Truck Tire is the perfect choice.
Not only are these tires built for performance, but they're also designed with safety in mind. With advanced tread patterns and other features that help prevent slippage and other accidents, you can trust that your vehicles will stay stable and safe while on the job.
■Off-road pattern block ensures powerful traction and good self-cleaning ability
■Chip, cut and abrasion resistance tread compound
■Deep tread depth and wide tread width increase mileage and service life
Size |
Ply Rating |
Load Index |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Max Load |
Inflation Pressure (kPa) |
Type | ||||||||
Dual | Single | |||||||||||||||||
12.00R24 | 18 | 158/155 | F | 8.5 | 315 | 1238 | 32 | 3875 | 4250 | 830 | TT | |||||||
20 | 160/157 | F | 8.5 | 315 | 1238 | 32 | 4125 | 4500 | 900 | TT | ||||||||
22 | 162/158 | B | 8.5 | 315 | 1238 | 32 | 4250 | 4750 | 900 | TT |
■Wide and big transverse grooves deliver better cut resistance for short one-way distance application
■Outstanding tire life and exceptional resistance to aggression
■Standard tread compound design,balancing cutting and heat resistance
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
14.00R24 | ☆☆☆ | E-3 | B | 10.00W | 375 | 1370 | 29.5 | 5800 | 700 | S2 | TT |
■Wide and big transverse grooves deliver outstanding tire life and exceptional resistance to aggression
■New bead area and more robust architecture increase more load capacity
■Diversified tread compounds meet performance requirements in different scenarios
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
14.00R25 | ★★★ | E-3 | B | 10.00/2.0 | 361 | 1354 | 27 | 5800 | 700 | C2/S2 | TT/TL | |||||||
16.00R25 | ★★★ | E-3 | B | 11.25/2.0 | 437 | 1492 | 31 | 8000 | 800 | C2/S2/S3 | TT/TL |
■Wide and big transverse grooves deliver better cut resistance for short one-way distance application
■Outstanding tire life and exceptional resistance to aggression
■Diversified tread compounds meet performance requirements in different scenarios
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
14.00R25 | ☆☆☆ | E-3 | B | 10.00 | 375 | 1371 | 27 | 5800 | 700 | C2/S1/S2 | TT/TL | |||||||
16.00R25 | ☆☆☆ | E-3 | B | 11.25/2.0 | 437 | 1492 | 31 | 8000 | 800 | C2/S1/S2 | TT/TL |
■Unique compoud for enhanced cutting resistance and long tread life
■Block pattern for effective heat dissipation and long one-way distance application
■Standard tread compound design, balancing cutting and heat resistance
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
14.00R25 | ☆☆☆ | E-3 | B | 10.00 | 361 | 1354 | 27 | 5800 | 700 | S1 | TT/TL |
■Proper horizontal tread pattern balances cut resistance and heat generation for medium one-way distance application
■Diversified tread compounds meet performance requirements in different scenarios
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
14.00R25 | ☆☆☆ | E-3 | B | 10.00 | 361 | 1354 | 27 | 5800 | 700 | S1/S2/S3 | TT/TL |
■Reinforced carcass for higher load capacity and explosion-proof performance
■Aggressive tread pattern for enhanced cutting and slipping resistance
■Diversified tread compounds meet performance requirements in different scenarios
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
16.00R25 | ☆☆☆ | E-3 | B | 11.25/2.0 | 437 | 1492 | 27 | 8000 | 800 | C2/S1/S2 | TT/TL |
■Deeper tread depth delivers longer life
■Reinforced carcass for higher load capacity and explosion-proof performance
■Aggressive tread pattern for enhanced cutting and slipping resistance
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
16.00R25 | ☆☆☆ | E-3 | B | 11.25/2.0 | 437 | 1492 | 31 | 8000 | 800 | C2/S1/S2 | TT/TL |
■Unique compoud for enhanced cutting resistance
■Tough casing construction for enhanced impact and cut resistance surpport
■Deep lug pattern tread delivers longer service life and better traction capacity
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
14.00R25 | ☆☆☆ | E-4 | B | 10.00 | 361 | 1374 | 37 | 5800 | 700 | C2/S1 | TT/TL | |||||||
16.00R25 | ☆☆☆ | E-4 | B | 11.25/2.0 | 432 | 1527 | 42 | 8000 | 800 | C2/S1 | TT/TL |
■Self-cleaning pattern design improves tire traction and adhesion
■Reinforced carcass for higher load capacity and explosion-proof performance
■Block pattern for effective heat dissipation and long one-way distance application
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
480/95R29 | ★★★ | E-3 | B | 13.00/2.5 | 490 | 1634 | 32 | 10500 | 800 | C2/S1 | TT/TL |
■Special compounds for exceptional wear and cut resistance
■Self-cleaning tread design provides good traction and stability on the soft and muddy ground
■Deeper tread depth ensures exceptional tread wear
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
18.00R33 | ★★ | E-4 | B | 13.00/2.5 | 498 | 1877 | 52 | 10900 | 700 | S1 | TL |
■Special tread compound for exceptional wear and cut resistance
■Self-cleaning tread design provides good traction and stability on the soft and muddy ground
■Deeper tread depth ensures exceptional tread wear
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
18.00R25 | ★★ | E-4 | B | 13.00/2.5 | 498 | 1673 | 46 | 9250 | 700 | S1 | TL | |||||||
★★★ | E-4 | B | 13.00/2.5 | 498 | 1673 | 46 | 10300 | 800 | S1 | TL | ||||||||
24.00R35 | ★★ | E-4 | B | 17.00/3.5 | 658 | 2164 | 66 | 18500 | 700 | C2/S1/S3/S4/H1 | TL | |||||||
27.00R49 | ★★ | E-4 | B | 19.50/4.0 | 730 | 2698 | 76 | 27250 | 700 | C2/S1/S3/S4/H1 | TL |
■New optimized sculpture with cooling vents
■Deep tread combined with sturdy shoulder and sidewall provide excellent traction and stability
■Multiple tread compound options target specific site requirements
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
27.00R49 | ★★ | E-4 | B | 19.50/4.0 | 730 | 2698 | 76 | 27250 | 700 | C2/S1/S3/S4/H1 | TL | |||||||
33.00R51 | ★★ | E-4 | B | 24.00/5.0 | 909 | 3048 | 87 | 38750 | 700 | C2/S1/S3/S4/H1 | TL |
■Optimized tread pattern design and cooling vents provide heat resistance
■Deeper tread depth ensures exceptional tread wear
■Multiple tread compound options target specific site requirements
Size |
Star Rating |
TRA Code |
Speed Index |
Rim |
Section Width (mm) |
Overall Diamter (mm) |
Tread Depth (mm) |
Load Capacity (kg) |
Inflation Pressure (kPa) |
Tread Compound |
Type | |||||||
46/90R57 | ★★ | E-4 | B | 29.00/6.0 | 1153 | 3579 | 95 | 63000 | 700 | S1/S3/S4/H1 | TL |
