Welcome to buy or customized Mini Truck Tire from LINGLONG factory at any time. We will provide you with factory good price for our products. Linglong is Mini Truck Tire manufacturers and suppliers in China.
Whether on the highway or around congested city streets, these mini truck tires offer an exceptional combination of safety, long-lasting tread wear and fuel-efficiency.
■ Zig-zag groove tread design reduces stone retention
■ Provides excellent traction in all weather condition
Size |
Ply Rating |
Load Index |
Speed Symbols |
Rim | Max.Load |
Inflated Pressure |
Section Width |
Overall Diameter |
Tread Depth |
Type | |||||
kg | lbs | kPa | psi | mm | inch | mm | inch | mm | 32ND | ||||||
5.00-10ULT | 8 | 79/77 | K | 3.50B |
D412 S437 |
D910 S965 |
400 | 58 | 143 | 5.6 | 517 | 20.4 | 8.0 | 10.1 | TT |
5.00-12ULT | 8 | 83/81 | K | 3.50B |
D462 S487 |
D1020 S1075 |
400 | 58 | 143 | 5.6 | 568 | 22.4 | 8.0 | 10.1 | TT |
10 | 88/86 | K | 3.50B |
D530 S560 |
D1170 S1235 |
500 | 73 | 143 | 5.6 | 568 | 22.4 | 8.0 | 10.1 | TT |
■ Zig-zag groove tread design reduces stone retention
■ Provides excellent traction in all weather condition
Size | Ply Rating | Load Index |
Speed Symbols |
Rim | Max.Load | Inflated Pressure | Section Width | Overall Diameter | Tread Depth | Type | |||||
kg | lbs | kPa | psi | mm | inch | mm | inch | mm | 32ND | ||||||
4.50-12ULT | 8 | 77/76 | K | 3.00B |
D400 S412 |
D880 S910 |
400 | 58 | 127 | 5.0 | 545 | 21.5 | 7.0 | 8.8 | TT |
■ Multi-functional pattern, suitable for mixed condition
Size | Ply Rating | Load Index |
Speed Symbols |
Rim | Max.Load | Inflated Pressure | Section Width | Overall Diameter | Tread Depth | Type | |||||
kg | lbs | kPa | psi | mm | inch | mm | inch | mm | 32ND | ||||||
5.00-12ULT | 8 | 83/81 | K | 3.50B |
D462 S487 |
D1020 S1075 |
400 | 58 | 143 | 5.6 | 568 | 22.4 | 8.0 | 10.1 | TT |
10 | 88/86 | K | 3.50B |
D530 S560 |
D1170 S1235 |
500 | 73 | 143 | 5.6 | 568 | 22.4 | 8.0 | 10.1 | TT | |
5.50-12ULT | 10 | 92/89 | K | 4J | 620 | 1365 | 530 | 77 | 160 | 6.3 | 594 | 23.4 | 8.0 | 10.1 | TT |
■ Provides excellent traction in all weather condition
Size | Ply Rating | Load Index |
Speed Symbols |
Rim | Max.Load | Inflated Pressure | Section Width | Overall Diameter | Tread Depth | Type | |||||
kg | lbs | kPa | psi | mm | inch | mm | inch | mm | 32ND | ||||||
4.50-10ULT | 6 | 60/57 | K | 3.50D |
D230 S250 |
D505 S550 |
300 | 44 | 120 | 4.7 | 470 | 18.5 | 7.0 | 8.8 | TT |
8 | 72/70 | K | 3.50D |
D335 S350 |
D740 S770 |
400 | 58 | 120 | 4.7 | 470 | 18.5 | 7.0 | 8.8 | TT |
